Charnwood Arc 7 with Store Stand

Charnwood Arc 7 with Store Stand

The Arc is a revolutionary new multi-fuel stove.
The Charnwood Arc 7 delivers an output of 7kW and is particularly suited to larger rooms or open plan areas. It is a true multi-fuel stove with exceptional clean burn technology. The Arc 7’s contemporary design features an inverted flue collar for a seamless flue connection.

Charnwood Arc 7 Features

• SIA Eco Design Ready
• Cleanburn airwash technology
• Quattroflow air management system
• Converting grate
• Drop down throat plat enabling the chimney to be swept through the stove
• Inverted flue collar for seamless flue connection
• DEFRA exempt for burning wood in smoke control areas
• Meets the UK building requirements for installation with a 12mm non-combustible hearth

Charnwood Arc 7 Customisation Options

• Flue boiler
• Vertical rear flue adaptor
• Rear heatshield
• Store stand
• Optional drawer
• Choice of eight colours

Energy output

• Output – 7kW (range 5-11kW)
• Net efficiency – 81% Wood, 79% Solid Fuel

Size and weight

• Flue outlet : Top or Rear 150mm (6″) diameter
• Max log length : 325mm (12.5”)
• Minimum distance to combustibles : Side: 270mm Rear: 150mm
• Weight (low stand) : 150kg
• Weight (store stand) : 170kg
